خرید و دانلود نسخه کامل کتاب CATIA V5-6R2023: Generative Drafting (ANSI)

The CATIA V5-6R2023: Generative Drafting (ANSI) learning guide enables you to use the generative capabilities of CATIA V5 to create an ANSI drawing from a 3D solid Part. This course is appropriate for new CATIA V5 users.Topics CoveredStart a generative drawingDefine the main viewsDefine section views and cutsDefine secondary views: detail, clipping, broken, breakout, auxiliary, isometric and unfolded viewsEdit a view and sheet propertiesAdd sheets to a drawingReposition viewsModify section, detail and auxiliary profilesModify section, detail and auxiliary graphical definitionsModify section hatching representationsCreate generative dimensions and tolerancesGenerate assembly drawingsCreate annotations and drawing tablesCreate balloonsCheck links to a solid 3D part and update a drawingAdd a title blockPrint the drawingSet drafting optionsPrerequisitesAccess to the V5-6R2023 version of the software, to ensure compatibility with this guide. Future software updates that are released by Dassault Systèmes may include changes that are not reflected in this guide. The practices and files included with this guide might not be compatible with prior versions (for example, V5-6R2022).Completion of at least one of the following courses (or equivalent experience) is highly recommended: CATIA V5-6R2023: Introduction to Modeling CATIA V5-6R2023: Introduction for Non-Designers
