خرید و دانلود نسخه کامل کتاب CATIA V5-6R2023: Sheet Metal Design

The CATIA V5-6R2023: Sheet Metal Design guide enables you to create features that are specific to the sheet metal modeling process. You are provided with a process-based approach to creating sheet metal models. Each step in the process is discussed in depth using lectures and several hands-on practices. This guide focuses on the Generative Sheetmetal Design workbench.Topics CoveredGenerative Sheetmetal Design workbenchSheet metal terminology, process, and parametersPrimary wall creation – profile, extruded, rolled, and hopperDefining wallsSecondary walls – wall on edge (automatic and sketch based), tangent, and sweptCylindrical bendsBends from flatUnfolded viewCorner reliefPoint and curve mappingCreating standard stamps – surface stamp, bead, curve stamp, flanged cutout, louver, bridge, flanged hole, circular stamp, stiffening rib, and dowelPunch and diePunch with opening facesSheet metal features – corners, chamfers, cuts, and holesFeature duplicationPatterning – rectangular patterns, circular patterns, and user patternsConverting a solid part to sheet metalOutput to DXF and drawingPrerequisitesAccess to the V5-6R2023 version of the software, to ensure compatibility with this guide. Future software updates that are released by Dassault Systèmes may include changes that are not reflected in this guide. The practices and files included with this guide might not be compatible with prior versions (e.g., V5-6R2022).Completion of CATIA V5-6R2023: Introduction to Modeling is recommended.
